Pre-Order your next Chapter 2 Kaha limited edition gravel bike.  All orders are custom built with three groupsets (Sram AXS Apex 1x12, Sram AXS Rival 1x 12 or Shimano GRX 1x 12).



The KAHA features fully integrated cabling via the MANA-GRVL Handlebar, Internal downtube storage compartment as well as a race ready and well balanced performance geometry.

The design brief for the KAHA was relatively simple, scratched onto the back of an envelope were the words “Controlled Speed”.



However, the journey to arrive at the perfect solution was anything but simple. We don’t want to skimp on practical details like storage, pannier/ fender racks, or ability to fit TT-Clip bars. Iteration after iteration, review after review, every little detail and decision was scrutinized to the nth degree.

Needless to say, all that effort was worth it, as the final deliverable achieves all the performance metrics we had envisioned for a High-Performance Gravel Racer.



Allow 8 weeks for assembling and shipping from date of order

Chapter 2 KAHA Gravel Bike

$4,999.00Price
Excluding Sales Tax
Color
  • Carbon:                  100% Made in Japan by Toray
    Frame 5 Sizes:       XS, S, M, L & XL
    Fork Rakes (2):      XS, S (65mm offset) and M, L, XL (55mm offset)
    Frame Weight:       1,099g Size M +/-3%
    Fork Weight:           409g +/-3%
    Handlebar/Stem (MANA-GRVL): 330g (100x491mm) +/-3%
    Headset:                    1.5” C2 Integrated System
    Tire Clearance:       47mm (700C) & 47mm (650B)
    Brake Type:              Disc Only (140 & 160 Rotors)
    Bottom Bracket:     Internal T47 (85.5)
    Safety Standard:   EN ISO 4210:2014

  • Wheelset:    Boyd GVL 700C ALLOY (25mm internal width) 875g front / 1020g rear (700c)

    Saddle:      Selle San Marco

    Tires:          Continental Gravel Kings 40mm

    Crank Size:  Frames Ordered in XS-SM come with 170mm Cranks, Medium comes with 172.5mm, LG & XL comes with 175mm cranks
